Model:BT-MO
Place of Origin: Guangdong China (Mainland)
Usually Ships in 3-5 days
Important Notice!
Item will be drop shipped directly from the
manufacturer/distortion-cancelable and
non-returnable.Usually ships in 3-5 days
Product Details
Key Features:
* Double layer of Die-cast Aluminum sell install easily and quickly, can dissipate heat more sufficiently. Black inner shell makes sharper monitor
* Be compatible with common cassette mechanism of camera, like SONY, HITACHI, LG and other famous brands with high resolution
* Running smoothly with low speed, subwoofer noise and no image dithering
* 64 preset positions.
* 1 Patrol tracking routs and 1 auto level scan routs.
* Variable rotation(pan 0 ¡« 80º/s ;tilt 0 ¡« 40º/s); Auto level scan
* Continuous 360 º rotations in Omni-directions with no fade zone; Rotation speed can be adjusted by tilting angle of the joystick
* Auto flips with vertical 180 º in Omni-directions, no fade zone.
* RS485 integrated various of protocols, PELCO-D,PELCO-P etc
* 3 class lightning defend, built in 3000V lightning proof, surge resistant
* IP 66 outer cover with all day protection; Built-in auto thermostatic control system
Specification:
Electrical specifications | |
Power Input | AC24V/2A (no identity "+"or "-") |
Power Consumption | 36W |
Settings: | |
Decoder | Built-in |
Electric machine | Excellent stepping motor |
Preset Position | 64 presets |
Left&Right Rotation Range | 360¡ãContinuous Rotation |
Left&Right Speed | 0.1¡ã£80¡ã/S |
Up&Down Rotation Range | 90¡ãVertical, 180¡ãAuto flip |
Up&Down Speed | 0.1¡ã£40¡ã/S |
Control Method | RS485 |
Protocol | Pelco-P/D etc |
Baud rate | 2400bps/4800bps/9600bps/19200bps |
Working environment: | |
Working Temperature | Indoor:0ºC ~ 50ºC,Outdoor:-40ºC ~60ºC |
Level of Protection | IP66 Shell, Lightning Proof, Surge Resistant |
Physical: | |
Packing Dimension(mm) | L355mm*W330mm*H410mm |
Weight (kg) | Wall Mount: 5.75kg Lifting Mount: 5.9 kg |
